Pail Filling and Capping Machine 30L for Ink, Paint, and Motor Oil

Guangzhi’s automated 30L pail filler/capper delivers ±0.25% accuracy & leak-proof seals. ATEX-certified. 85% labor reduction & near-zero spills. Free demo!

  • Brand: glzon
  • Model: GZM_30L

Automated Pail Filling & Capping Machine GZ-PFC800 Series

*Integrated Solution for 30L Pails: Precision Filling + Leak-Proof Sealing*
Shanghai Guangzhi Automation’s GZ-PFC800 Series automates the packaging of inks, paints, and motor oils into 30L industrial pails with ±0.25% weight accuracy and 15 pails/hour throughput. This ATEX/CE-certified system combines gravimetric filling, torque-controlled capping, and vapor-recovery technology to eliminate spills, reduce labor by 85%, and ensure OSHA-compliant handling of solvents and volatile compounds.

Automatic Pail Filling and Capping Machine


Core Engineering Innovations

  1. Closed-Loop Filling & Capping

    • Net-Weight Filler: Load-cell-controlled servo pumps adjust for viscosity shifts (1–100,000 cP) with ±0.25% accuracy.

    • Auto Capper: Applies screw caps/lids with 10–50 Nm torque (programmable for leak-proof seals).

  2. Vapor & Spill Containment

    • Sealed Filling Chamber: Nitrogen inertization + vapor recovery (≤10 ppm VOC emissions).

    • Drip-Free Nozzles: Vacuum suck-back + anti-static tips prevent static discharge in solvents.

  3. Corrosion-Resistant Build

    • 316L SS/PTFE Fluid Path: Resists pigment abrasion (inks), alkyd resins (paints), and sulfur compounds (motor oils).

    • ATEX Zone 1 Option: Explosion-proof electronics for flammable vapors (e.g., toluene, mineral spirits).

  4. Operator-Safe Automation

    • Robotic Pail Handling: Automatic positioning/clamping; no manual lifting.

    • HMI Diagnostics: 12" touchscreen with OEE tracking and jam alerts.


Technical Specifications

ParameterSpecification
ModelGZ-PFC800-Pro
Pail Capacity30L (range: 20–50L)
Filling Accuracy±0.25%
Capping Torque10–50 Nm (adjustable)
Throughput15 pails/hour
Viscosity Range1–100,000 cP
VOC Recovery>95% efficiency (optional)
Power380V/50Hz, 5.5 kW
Air Supply0.7 MPa, 0.4 m3/min
Footprint (L×W×H)3200 × 1500 × 2400 mm
ComplianceATEX, CE, OSHA 1910.106, ISO 80079

Performance vs. Manual Process

MetricGZ-PFC800 AutomatedManual Operation
Output (8h)120 pails24 pails
Labor0.5 operators3 operators
Spillage Loss<0.1%4–12%
Seal Failure Rate0.01%2–5%
ROI Period7–11 monthsN/A

Industry-Specific Adaptations

  • Inks: Nitrogen purge prevents skinning; conductive hoses (106–109 Ω resistance).

  • Paints: Self-cleaning nozzles for pigment-rich formulas; Agitator-equipped hopper.

  • Motor Oils: High-flow filling (40 L/min); API/SAE-compliant material traceability.



APPLICABLE BARREL TYPE

Drum Filling Machine

COMPANY PROFILE

Shanghai Guangzhi Automation Equipment Co., Ltd. is a production and trading company specializing in the weighing industry. We are located in Shanghai, China's economic city, with convenient transportation and export ports all over the world. We cooperate with state-owned factories and international companies, and the quality is guaranteed.

We mainly focus on providing customers with weighing solutions, from commercial scales to industrial weighing machines. Such as pneumatic valve bag packaging machine, dry mix mortar bag packaging machine, cement packaging machine, natural stone powder packaging machine, flour powder packaging machine, wheat packaging machine, potato starch packaging machine, air packaging machine, granule bag packaging machine, grain packaging machine, fertilizer bag packaging machine, lubricant filling machine, 200 kg drum filling machine, 216L drum filling machine, 208L drum filling machine, ton barrel filling machine, IBC barrel filling machine, jumbo bag packaging machine, ton bag packaging machine, 30L pail filling machine, 50L pail asphalt filling machine, ATEX barrel filling machine, explosion-proof filling machine, etc.

Drum Filling Machine

Company Certificate

Drum Filling Machine

Our office and workshop

Consulting-Design-Procurement-Processing-Production-Installation-Debugging-Training-Maintenance

Drum Filling Machine


This is a partial Drum Filling MachineDrum Filling Machine

service for us

in China.

Over 30 years of experience, every time we produce in

Shanghai, our friends can visit our factory at any time.






Brand components

We will ensure that our company's equipment has safety, stability, high efficiency and intelli-gent technology, so as to meet your needs, we can also cooperate with you in selecting in-ternational product brand production and business.

Drum Filling Machine


Our service

Complete solution provided

Telephone exchange joint business design plan, you can also visit our company ; we have a good environmental office vehicle,you can visit from time to time.


Duty after death

Our music team has a strong heart, and the customer's suspicions are also the purpose 24 hours of phone cell service and listing to the conversation at any time.


Technology group

We have a wealth of technical personnel and our technical team has been developing technical skills for over ten years.


Successful collaboration

Our factory in Shanghai. China provides free training for our technical staff.Better guarantee good product safety , our company provides safety, convenience, high efficlency packaging servic.

packge and delivery

Multiple Transportation way :Express(Fedex/DHL/TNT/EMS/UPS etc),air and shipping for your choose

Drum Filling Machine

FAQs

Our in-house designers and engineers have produced countless great designs for customers from different industries

1
Can we get your free samples?
Samples can be offered for free. But courier cost for the samples should be at buyer's account.
2
Can you print our LOGO in flatware set?
Yes.we can print the logo on the flatware set as your requirements.Embossed, laser,stamped and engraved are available.
3
How long is the delivery time of sample?
Samples from stock can be sent within 1-3 days. New produced samples will be sent within 5-15 days.
4
Is there any MOQ for what I purchase?
Yes, we have MOQ for mass production. Different item with different package has different MOQ. Please contact us for more details.
5
Do you accept OEM or ODM services?
OEM and ODM are accepted!
6
What is 18-10 Stainless Steel Flatware?
18-10 refers to the composition of stainless steel. It contains 18% chromium and 10% nickel for excellent strength and corrosion resistance.
