ChemiFill Pro CF-3000 Series200L Semi-Automatic Liquid Ink & Chemical Filling SystemPrecision Gravimetric Weighing • 25 Drums/Hr • ±0.1% Accuracy • ATEX Zone 2 • VOC ContainmentCore Engineering In
200L Semi-Automatic Liquid Ink & Chemical Filling System
Precision Gravimetric Weighing ? 25 Drums/Hr ? ±0.1% Accuracy ? ATEX Zone 2 ? VOC Containment
Performance Validation:
| Parameter | CF-3000 Performance | Regulatory Limit |
|---|---|---|
| Benzene Emission | 0.8ppm | EPA 5ppm |
| Static Charge | <0.5kV | NFPA 77 <10kV |
| Spill Volume | <0.05L/drum | OSHA Reportable 1.9L |
| Component | Technology | Accuracy |
|---|---|---|
| Load Cells | Temperature-Compensated Strain Gauges | ±0.05% FS |
| Air Buoyancy | Real-Time Atmospheric Compensation | ±0.1% Error |
| Flow Control | Adaptive PID + Coriolis Meter | ±0.1% Consistency |
| Parameter | CF-3100 (Standard) | CF-3200X (ATEX) | CF-3300P (Pharma-Grade) |
|---|---|---|---|
| Capacity | 200L (±0.1%) | 200L (±0.15%) | 200L (±0.08%) |
| Throughput | 25 Drums/Hour | 22 Drums/Hour | 20 Drums/Hour |
| Accuracy | ±0.1% Gravimetric | ±0.15% | ±0.08% |
| Viscosity Range | 50-500,000 cP | 100-300,000 cP | 10-1,000,000 cP |
| Filling Technology | Servo Piston + Mass Flow Meter | ATEX Diaphragm Pump | Peristaltic Pump (FDA) |
| Material Contact | 316L SS (Ra<0.8μm) | Hastelloy C276 | Glass-Lined Path |
| Containment System | Triple Barrier:<br>1. Nitrogen Blanketing<br>2. Carbon Adsorption<br>3. -0.5bar Vacuum Hood | Same + Explosion Venting | VHP Sterilizable |
| Drip Control | Laser-Cut Capillary Break | Spring-Loaded Nozzle | PTFE Scraper + Vacuum |
| Weighing System | Unipulse F701-C Controller<br>? 24-bit Resolution<br>? 0.3μV Sensitivity<br>? SIL-2 Certified | Same | cGMP Data Integrity |
| Clamping Mechanism | Robotic Auto-Centering<br>±0.5mm Accuracy<br>100-500N Force | Same + ATEX Gripper | Magnetic Levitation |
| Changeover Time | <90s (Tool-Free) | <110s | <75s |
| Power | 380V/50Hz, 7.2kW | 24VDC Ex ia | 380V/50Hz, 6.5kW |
| Certifications | CE, ISO 9001 | ATEX Zone 2 | FDA 21 CFR 175.300 |
Liquid Inks & Pigments
| Challenge | Innovation | Performance |
|---|---|---|
| Color Consistency | In-line Viscosity Control | ±2% Brookfield |
| Settling Prevention | Pulsed Ultrasonic Agitator | 99.8% Uniformity |
| Foam Control | Vacuum Degassing (-0.7bar) | 0% Entrained Air |
Chemical Solvents
Explosion Safety:
Corrosion Resistance:
| Component | Chemical Compatibility |
|---|---|
| Flow Path | Zirconium Alloy |
| Seals | Kalrez?6375 (-20°C to 327°C) |
Pharmaceutical Liquids
| Feature | cGMP Compliance |
|---|---|
| Cleanability | SIP Validation (121°C/30min) |
| Data Integrity | 21 CFR Part 11 Audit Trail |
| Material Traceability | RFID/NFC Tracking |
**10" HMI with ChemiOS?**
AI-Driven Features:
Quality Guardian:
| Parameter | Action |
|---|---|
| Viscosity Shift >5% | Flow Profile Adjustment |
| Density Variance >0.3% | Formula Correction |
Zero-Downtime:
| Component | Alert Threshold |
|---|---|
| Pump Wear | Vibration >4.5mm/s |
| Seal Degradation | Friction >8N |
1. Manual Drum Loading → 2. Auto-Clamping (±0.5mm) → 3. Nitrogen Purging (O?<0.5%) → 4. Precision Filling (±0.1%) → 5. Vacuum Nozzle Retract → 6. Torque-Sealing (30-100 N·m) → 7. Weight Verification → 8. Palletizing
Cycle Time: 144 seconds/drum
Precision & Safety Excellence
? Gravimetric Superiority: | **Technology**| **Performance**| |-------------------------|------------------------| | Unipulse F701-C| 0.3μV Resolution | | Air Buoyancy Compensation | ±0.05% Accuracy| | Real-Time PID | ±0.1% Consistency | ? Zero-Emission Architecture: 1. Nitrogen Blanketing (O?<0.5%) 2. Activated Carbon VOC Capture (99.95%) 3. -0.5bar Vacuum Containment ? Industrial Durability: - Tungsten Carbide Components (2,200 Hv) - IP66 Washdown Protection - 100,000-Hour MTBF
? ATEX 2014/34/EU Zone 2 ? FDA 21 CFR 175.300 ? ISO 9001:2015
BASF Ludwigshafen Facility:
"After implementing CF-3200X for solvent-based inks:
Output: 14 → 25 Drums/Hour (+79%)
VOC Emissions: 28kg/day → 0.5kg/day
Accuracy: ±0.8% → ±0.09%
ROI Period: 6.5 months"
APPLICABLE BARREL TYPE
