PrecisionFill PF-5000 SeriesSemi-Automatic 200L Drum/IBC Filling System for Paints & LiquidsIndustrial-Grade Gravimetric Accuracy • 25 Drums/Hr • ±0.15% Tolerance • Splatter-Free • ATEX/FDA Dual C
Semi-Automatic 200L Drum/IBC Filling System for Paints & Liquids
Industrial-Grade Gravimetric Accuracy ? 25 Drums/Hr ? ±0.15% Tolerance ? Splatter-Free ? ATEX/FDA Dual Compliance
| Parameter | PF-5100 (Standard) | PF-5200X (ATEX) | PF-5300F (Food-Grade) |
|---|---|---|---|
| Capacity | 200L (±0.15%) | 200L (±0.2%) | 200L (±0.1%) |
| Throughput | 25 Drums/Hour | 22 Drums/Hour | 20 Drums/Hour |
| Accuracy | ±0.15% Gravimetric | ±0.2% | ±0.1% |
| Viscosity Range | 50-500,000 cP | 100-300,000 cP | 10-1,000,000 cP |
| Filling Technology | Servo Piston + Coriolis Meter | ATEX Gear Pump | Peristaltic Pump (FDA) |
| Material Contact | 316L SS (Ra<0.8μm) | Hastelloy C276 | Electropolished 316L (Ra<0.4μm) |
| Splatter Control | Vacuum-Assisted Submerged Nozzle | Air Cushion Technology | Coanda Adhesion Flow |
| Container Compatibility | Drums ? IBCs ? Jerrycans<br>Lid Types: Bung ? DIN ? Tri-Clamp | Same + Safety Containers | Aseptic RTP Port |
| Weighing System | 4-Point Load Cells<br>Resolution: 0.05kg<br>OIML R51 Certified | Same + SIL-2 Certification | FDA 21 CFR Part 11 |
| Changeover Time | <90s (Tool-Free) | <120s | <80s |
| Power | 380V/50Hz, 8.5kW | 24VDC Ex ia | 380V/50Hz, 7.2kW |
| Certifications | CE, ISO 9001 | ATEX Zone 2 | FDA 21 CFR 175.300 |
Performance Validation:
| Material | Viscosity | Residual Splatter | Industry Standard |
|---|---|---|---|
| Latex Paint | 20,000 cP | <0.5ml | 15-25ml |
| Epoxy Resin | 80,000 cP | <0.8ml | 20-40ml |
| Solvent-Based Coating | 300 cP | 0ml | 5-10ml |
| Component | Technology | Performance |
|---|---|---|
| Load Cells | Temperature-Compensated Strain Gauges | ±0.05% FS Accuracy |
| Air Buoyancy | Real-Time Atmospheric Compensation | ±0.1% Environmental Error |
| Flow Control | Adaptive PID Algorithm | ±0.15% Bag-to-Bag Consistency |
Paints & Coatings
| Challenge | Innovation | Certification |
|---|---|---|
| Skin Formation | Nitrogen Blanketing (O?<0.1%) | ASTM D1544 |
| Color Separation | Low-Shear Paddle Agitator | ΔE<0.5 (ASTM D2244) |
| VOC Emission | Activated Carbon Adsorption | EPA Method 25 |
Chemical Solvents
Explosion Safety:
Material Compatibility:
| Chemical | Compatibility |
|---|---|
| Acetone | Hastelloy C276 Path |
| Xylene | PTFE-Lined Components |
| MIBK | Zirconium Alloy Seals |
Food-Grade Liquids
| Feature | EHEDG Compliance |
|---|---|
| Cleanability | Ra<0.4μm Electropolished |
| Seal Material | FDA Silicone (Platinum-Cured) |
| Data Integrity | 21 CFR Part 11 Audit Trail |
**10" HMI with PaintOS?**
AI-Driven Features:
Quality Assurance:
| Parameter | Action |
|---|---|
| Viscosity Shift >10% | Flow Profile Adjustment |
| Density Variance >0.5% | Formula Correction |
Preventive Maintenance:
| Component | Alert Threshold |
|---|---|
| Pump Wear | Vibration >4.5mm/s |
| Seal Degradation | Friction >10N |
1. Manual Container Loading → 2. Auto-Nozzle Alignment (±1mm) → 3. Submerged Filling (±0.15%) → 4. Vacuum Nozzle Retraction → 5. Torque-Controlled Lid Sealing (30-100 N·m) → 6. Weight Verification → 7. Palletizing
Cycle Time: 144 seconds/drum
Precision Engineering
? Zero-Waste Architecture: | **Technology**| **Performance**| |-------------------------|------------------------| | Capillary Break Valve | <0.1ml Residual| | Coanda Adhesion | 0 Droplet Formation | | Overflow Prevention | 0.1% Cutoff Accuracy| ? Splatter-Free Guarantee: 1. -0.8bar Vacuum Suction 2. Laminar Flow Nozzle Design 3. Nano-Hydrophobic Coating ? Industrial Durability: - Tungsten Carbide Contact Points (2,200 Hv) - IP66 Washdown Protection - 100,000-Hour MTBF
? ATEX 2014/34/EU Zone 2 ? FDA 21 CFR 175.300 ? EHEDG EL Class I ? ISO 9001:2015
PPG Industrial Coatings:
"After implementing PF-5200X:
Output: 15 → 25 Drums/Hour (+67%)
Material Savings: 2.8% → 0.18%
VOC Emissions: ↓92% (Carbon Adsorption)
ROI Period: 6.5 months"
APPLICABLE BARREL TYPE
