QuadroFlex QF-10000 SeriesMultifunctional Open Architecture Packaging System4-in-1 Versatility • 50% Faster Changeover • Industry 4.0 ReadyTechnical SpecificationsParameterQF-1010 (Standard)QF-1020X (
Multifunctional Open Architecture Packaging System
4-in-1 Versatility ? 50% Faster Changeover ? Industry 4.0 Ready
| Parameter | QF-1010 (Standard) | QF-1020X (ATEX) | QF-1030P (Pharma Grade) |
|---|---|---|---|
| Container Compatibility | Drums/IBCs/Totes/Boxes (20-2000L) | Same + Jerrycans | Same + Pharma Cans |
| Material Handling | Liquids/Powders/Pastes/Granules | Same + Flammables | Aseptic Products |
| Throughput | 30 Units/Hour | 28 Units/Hour | 25 Units/Hour |
| Changeover Time | <5 min (Tool-Free) | <6 min | <4 min (CIP Validated) |
| Accuracy | ±0.15% Gravimetric | ±0.2% | ±0.08% |
| Viscosity Range | 0.5-5,000,000 cP | 1-3,000,000 cP | 1-500,000 cP |
| Open Architecture | API-Enabled PLC | OPC UA + MQTT | 21 CFR Part 11 Compliance |
| Module Hot-Swap | 4 Bay System (Filling/Capping/Labeling/Palletizing) | Same | Same + SIP Module |
| Material Contact | 316L SS + PEEK Coated | Hastelloy C276 | 316L EP (Ra<0.4μm) |
| Power | 480V/60Hz, 15kW | 24VDC Ex ia | 480V/60Hz, 12kW |
| Footprint (L×W) | 6.5m × 3.8m | 7.0m × 4.2m | 6.8m × 4.0m |
| Certifications | CE, ISO 9001 | ATEX Zone 1/21 | FDA cGMP, EHEDG |
Changeover Performance:
| Task | QF-1010 | Traditional |
|---|---|---|
| Filling ? Capping | 45s (Magnetic Coupling) | 15-25 min |
| Liquid ? Powder | 90s (Quick-Release Hopper) | 30-45 min |
| Container Type Change | 120s (AI Vision Auto-Adjust) | 20-40 min |
Chemicals & Solvents
| Feature | Specification |
|---|---|
| ATEX Zone 1 | Pressurized Cabinets (+50Pa) |
| VOC Recovery | >99% Carbon Adsorption |
| Corrosion Proof | Zirconium Flow Path |
Food & Pharma
Cross-Contamination Prevention:
| Technology | Performance |
|---|---|
| CIP/SIP | 4-log Reduction |
| Allergen Control | Dedicated Paths |
Data Integrity:
Building Materials
| Component | Function |
|---|---|
| Abrasion Resistance | Tungsten Carbide Liner (2,200 Hv) |
| High-Density Filling | 3-Stage Vibration Compaction |
| Dust Explosion Proof | ATEX Category 1D |
15" IIoT HMI with FlexOS?
AI-Driven Features:
Anomaly Response:
| Situation | Action |
|---|---|
| Viscosity Shift | Auto-Temp Compensation |
| Container Misalignment | Robotic Re-Positioning |
Energy Optimization:
| Mode | Savings |
|---|---|
| Standby | 85% Power Reduction |
| Partial Load | Frequency Control |
BASF Ludwigshafen Case Study:
*"After implementing QF-1020X:
Changeover Time: 38 min → 4.5 min
OEE: 68% → 92%
Product Range: 3 → 12 product lines
ROI: 11 months"*
? ATEX 2014/34/EU (QF-1020X) ? FDA 21 CFR 211.68 ? ISO 9001:2015 ? CE EN 415-1
APPLICABLE BARREL TYPE
COMPANY PROFILE
Shanghai Guangzhi Automation Equipment Co., Ltd. is a production and trading company specializing in the weighing industry. We are located in Shanghai, China's economic city, with convenient transportation and export ports all over the world. We cooperate with state-owned factories and international companies, and the quality is guaranteed.
We mainly focus on providing customers with weighing solutions, from commercial scales to industrial weighing machines. Such as pneumatic valve bag packaging machine, dry mix mortar bag packaging machine, cement packaging machine, natural stone powder packaging machine, flour powder packaging machine, wheat packaging machine, potato starch packaging machine, air packaging machine, granule bag packaging machine, grain packaging machine, fertilizer bag packaging machine, lubricant filling machine, 200 kg drum filling machine, 216L drum filling machine, 208L drum filling machine, ton barrel filling machine, IBC barrel filling machine, jumbo bag packaging machine, ton bag packaging machine, 30L pail filling machine, 50L pail asphalt filling machine, ATEX barrel filling machine, explosion-proof filling machine, etc.
