PhosFill PF-8000 SeriesFully Automatic Explosion-Proof Phosphoric Acid Filling System for Metal PailsATEX Zone 0 Certified • 40 Pails/Hr • ±0.05% Accuracy • Corrosion-Resistant • Triple ContainmentCor
Fully Automatic Explosion-Proof Phosphoric Acid Filling System for Metal Pails
ATEX Zone 0 Certified ? 40 Pails/Hr ? ±0.05% Accuracy ? Corrosion-Resistant ? Triple Containment
| Parameter | PF-8100 (Standard) | PF-8200X (ATEX Zone 0) | PF-8300P (High-Purity) |
|---|---|---|---|
| Capacity | 20-50L (±0.05%) | 20-50L (±0.08%) | 20-50L (±0.03%) |
| Throughput | 40 Pails/Hr | 36 Pails/Hr | 35 Pails/Hr |
| Accuracy | ±0.05% Gravimetric | ±0.08% | ±0.03% |
| Acid Concentration | Up to 85% H?PO? | Same | Ultra-Pure (SEMI Grade) |
| Explosion Protection | ATEX Zone 0/20 | IECEx Zone 0 | ATEX + cGMP |
| Filling Technology | Coriolis Mass Flow + Gear Pump | ATEX Diaphragm Pump | Peristaltic Pump (FDA) |
| Material Contact | Zirconium R60702 | Hastelloy C276 | PFA-Lined Zirconium |
| Containment System | TripleShield?:<br>1. N? Inerting (O?<0.3%)<br>2. -0.8bar Vacuum Hood<br>3. Double Mechanical Seals | + Explosion Venting | VHP Sterilization |
| Corrosion Resistance | 0.001 mm/yr (ASTM G31)<br>Temp Range: -20°C to 100°C | Same | 0.0005 mm/yr (SEMI F20) |
| Static Control | Ionized Air Curtain<br>? 10? ions/cm3 Output<br>? <0.1kV Surface Charge<br>? SIL-3 Spark Detection | NFPA 77 Compliance | Conductive Path (<10? Ω) |
| Pail Compatibility | Steel/Stainless Pails<br>Lid: Camlock ? Tri-Clamp ? Bolt Seal | UN-Certified Containers | Electropolished Pails |
| Changeover Time | <120s (Tool-Free) | <150s | <90s |
| Power | 480V/60Hz, 15kW | 24VDC Ex ia | 480V/60Hz, 14kW |
| Certifications | CE, ISO 9001 | ATEX/IECEx Zone 0 | SEMI F20/F44 |
Material Validation:
| Material | 85% H?PO? @80°C | 316L SS | Hastelloy C276 |
|---|---|---|---|
| Zirconium R60702 | 0.001 mm/yr | 25 mm/yr | 0.8 mm/yr |
| PFA-Lined Zirconium | 0.0005 mm/yr | Dissolves | 0.6 mm/yr |
| Layer | Technology | Certification |
|---|---|---|
| Primary Seal | Double Cartridge Seal | API 682 Plan 53B |
| Secondary Barrier | -0.8bar Vacuum Hood | ASME BPE-2022 |
| Tertiary Capture | Activated Carbon Adsorption | EPA Method 115 |
1. AGV Pail Loading → 2. Robotic Lid Removal → 3. Nitrogen Purging (O?<0.3%) → 4. Submerged Filling (±0.05%) → 5. Vacuum Hood Retract → 6. Helium Leak Test (<10?? mbar·L/s) → 7. Torque-Sealing (80-200 N·m) → 8. Palletizing
Cycle Time: 90 seconds/pail
Extreme Environment Engineering
? Corrosion Immunity: | **Component** | **Material Science**| |----------------------|------------------------------| | Flow Path| Zirconium R60702 (0.001mm/yr) | | Seals| Kalrez?6375 + PTFE Encapsulation | | Sensors| Zirconia-Oxygen Probes| ? Explosion-Safe Architecture: 1. ATEX Zone 0 Certification (Category 1G) 2. SIL-3 Spark Detection (0.1s Response) 3. Nitrogen Inerting (O?<0.3%) ? Zero-Emission Operation: - 99.97% VOC Carbon Adsorption - Double Mechanical Seals - Helium-Verified Containment
? ATEX 2014/34/EU Zone 0 ? IECEx IEC 60079-0/1/7/31 ? SEMI F20/F44 (Semiconductor Grade) ? API 682 Plan 53B
Mosaic Fertilizer Production Facility:
"After implementing PF-8200X:
Output: 22 → 40 Pails/Hr (+82%)
Acid Loss: ↓98% (Triple Containment)
Corrosion Failures: 3/month → 0
ROI Period: 7 months"
